Dimensions
Dry Weight Dry – 535 lb. (243 kg)Running order – 555 lb. (252 kg)GVWR – 988 lb. (449 kg)
Fuel Capacity 3.4 gal. (13 l)
Ground Clearance 4.4 in (113 mm)
Lean Angle 33°
Rake/Trail 29.0° / 4.7 in (120 mm)
Wheelbase 61.5 in (1,562 mm)
Width 36.1 in (916 mm)
Engine
Bore and Stroke 4.094″ x 2.898″ (104mm x 73.6mm)
Compression Ratio 12.5:1
Displacement 1250cc
Engine Type Liquid Cooled V-Twin (60 degrees)
Final Drive 2.276:1
Fuel System Closed loop fuel injection / 63 mm bore
Maximum Torque 81 ft-lbs
Transmission 2.276:1
Chassis
Front Brake Front – Single / 298 mm Semi-floating rotor / 2 Piston caliperRear – Single / 298 mm Semi-floating rotor / 1 Piston caliperABS
Front Suspension Telescopic Fork
Front Tires Pirelli Night Dragon 130/90B16 67H
Rear Brake Front – Single / 298 mm Semi-floating rotor / 2 Piston caliperRear – Single / 298 mm Semi-floating rotor / 1 Piston caliperABS
Rear Suspension Dual Shocks
Rear Tires Pirelli Night Dragon 150/80B16 77H
Accessories & Other
Color Silver Quartz Smoke
Instruments/Display Analog speedometer, Digital tachometer, odometer, trip meter, engine temp, low fuel lamp.
Navigation Factory Installed:Polaris 4″ Indian
