Dimensions
Dry Weight As Shipped – 511 lb. (232 kg)Running Order – 531 lb. (241 kg)GVWR – 988 lb. (449 kg)
Fuel Capacity 3.4 gal (13.0 L)
Ground Clearance 4.4 in (113 mm)
Height 43.1 in (1,096 mm)
Lean Angle 33°
Length 91.3 in (2,318 mm)
Rake/Trail 29.0° / 4.8 in (122.2 mm)
Seat Height 25.7 in (654 mm)
Wheelbase 61.5 in (1,562 mm)
Width 35.8 in (910 mm)
Engine
Bore and Stroke 3.661 in x 2.898 in (93 mm x 73.6 mm)
Compression Ratio 11.0 : 1
Displacement 60 cu in (999 cc)
Engine Type Liquid Cooled V-Twin (60 degrees)
Final Drive 2.276 : 1
Fuel System Closed loop fuel injection / 54 mm bore
Maximum Torque 64 ft-lbs (87 Nm)
Transmission 2.276 : 1
Chassis
Front Brake Front – Single / 298 mm Rotor / 2 Piston CaliperRear – Single / 298 mm Rotor / 1 Piston Caliper
Front Suspension Telescopic Fork
Front Tires Pirelli Night Dragon 130/90B16 67H
Rear Brake Front – Single / 298 mm Rotor / 2 Piston CaliperRear – Single / 298 mm Rotor / 1 Piston Caliper
Rear Suspension Dual Shocks
Rear Tires Pirelli Night Dragon 150/80B16 77H
Accessories & Other
Color Springfield Blue
Instruments/Display 4″ Analog Gauge with Speedometer, Indicator Lamps, and Multi-Function Display
