Dimensions
Dry Weight Dry – 528 lb. (239 kg)Running order – 548 lb. (248 kg)GVWR – 988 lb. (449 kg)
Fuel Capacity 3.4 gal (13.0 L)
Ground Clearance 4.4 in (113 mm)
Height 45.5 in / 1155 mm
Lean Angle 33°
Length 86.9 in / 2206 mm
Rake/Trail 29.0° / 4.7 in (120 mm)
Seat Height 25.7 in (654 mm)
Wheelbase 61.5 in (1,562 mm)
Width 37.6 in / 956 mm
Engine
Bore and Stroke 4.094″ x 2.898″ (104mm x 73.6mm)
Compression Ratio 12.5:1
Displacement 1250cc
Engine Type Liquid Cooled V-Twin (60 degrees)
Final Drive 2.276:1
Fuel System Closed loop fuel injection / 63 mm bore
Maximum Torque 82 ft-lbs
Transmission Manual
Chassis
Front Brake Front – Single / 298 mm Semi-floating rotor / 2 Piston caliperRear – Single / 298 mm Semi-floating rotor / 1 Piston caliperABS
Front Suspension Telescopic Fork
Front Tires Metzeler Cruisetec 130/60B19 61H
Rear Brake Front – Single / 298 mm Semi-floating rotor / 2 Piston caliperRear – Single / 298 mm Semi-floating rotor / 1 Piston caliperABS
Rear Suspension Dual Shocks
Rear Tires Metzeler Cruistec 150/80B16 72H
Accessories & Other
Color Storm Blue
Instruments/Display Analog speedometer, Digital tachometer, odometer, trip meter, engine temp, low fuel lamp.
Navigation Factory Installed:Polaris 4″ Indian
