Dimensions
Bed Capacity 300
Dry Weight 2,578 lbs
Fuel Capacity 12.30 gal (46.56 L)
Ground Clearance 16 in (40.6 cm)
Height 76
Length 165
Overall Dimensions 165.5 x 74 x 76.5″ (420 x 188 x 194 cm)
Person Capacity 4
Towing Capacity N/A
Wheelbase 133.5 in (339.1cm)
Width 74
Engine
Bore and Stroke 2.93
Compression Ratio 12.5:1
Displacement 1997cc
Engine Type 4-Stroke DOHC Inline Four Cylinder
Final Drive Pro Performance True 2WD/4WD/4WD Lock
Fuel System Electronic Fuel Injection
Starting System Electric
Transmission Automatic PVT P / R / N / L / H
Chassis
Front Brake Front / Rear – 4-Wheel Hydraulic Disc with Triple-Bore Front and Dual-Bore Rear Calipers, Aluminum Top Hat Rotor Parking – Park In-Transmission
Front Suspension Light Weight Boxed Dual A-Arm with 3 piece Stabilizer Bar and 27.0 in (68.6 cm) *Usable Travel, 22.25 in (56.5 cm) Wheel Travel, Unitized Hubs
Front Tires 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15×7
Rear Brake Front / Rear – 4-Wheel Hydraulic Disc with Triple-Bore Front and Dual-Bore Rear Calipers, Aluminum Top Hat Rotor Parking – Park In-Transmission
Rear Suspension Boxed Trailing Arm with Toe Link, High-Clearance Radius Rods, and 3 Piece Stabilizer Bar and 29.0 in (73.7 cm) *Usable Travel, 24.5 in (62.2 cm) Wheel Travel, Unitized Hubs
Rear Tires 32 x 10-15 Maxxis Rampage Fury; 8-Ply Rated; Wheel Size 15×7
Accessories & Other
Color Black Crystal / Radiant Green
Instruments/Display RIDE COMMAND® 7” Glove-Touch Display: DYNAMIX 2.0 Visualizer, Built-In GPS, Group ride (cell-based or GPS based), Topographic Mapping, Bluetooth & USB Smartphone Connectivity, AM/FM & Weather Radio (Accessory Speakers Required – Sold Separately), In-Vehicle Communications Capable With Optional Sena Headsets, Polaris P.A.S.S Anti-Theft System. Dual-sweep Analog Dials w/ 4″ LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals. Digital Instrumentation: Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Coolant Temperature, Voltmeter, Service Indicator and Codes, Seat Belt Reminder Light, Gear Indicator, DC Outlet.
